Model LZ350G LZ354G LZ400G LZ404G LZ450G LZ454G LZ500G LZ504G
Type 4 x 2 4 x 4 4 x 2 4 x 4 4 x 2 4 x 4 4 x 2 4 x 4
Dimensions of Tractor(mm) Length 3230
Width 1250
Height 1150
Tread Front Wheel 905
Rear Wheel 980
Axle Base 1710
Min.Ground Clearance 240
Structure weight (kg)  1100
Ballast weight (kg) Front ballast 56
Rear ballast 110
Rated traction force (N) 5200 6900 5940 7880 6680 8870 7420 9850
Engine Model 4L22 4L22 4L22 4L22 4L22 4L22 LD4100 LD4100
Type Vertical,3-Cylinder,Water Cooled Vertical,4-Cylinder,Water Cooled and 4-stroke
Rated Power(kw) 25.7 25.7 29.4 29.4 33.1 33.1 36.8 36.8
Rated speed (r/min) 2400
Fuel Diesel
Tyre Front Wheel 400-12(2WD);    600-12(4WD)
Rear Wheel 9.5-16
Clutch Single-stage clutch Dual-stage clutch
Steering power steering
Transmission Type 8+2  or (8+2)×2 with creeper shift
Suspension Type 3-point links
PTO Type and Rev Semi-independent Type 720
Spline Size F35 Rectangle Spline with 6 teeth
